Special-shaped Steel Pipe Full Panoramic Padel Court-PD14

Special-shaped Steel Pipe Full Panoramic Padel Court Paddle Tennis Court

Internal dimensions of the Court: 20m x 10m;
External dimensions of the Court: 20.32m x 10.32m x 5.98m

Steel Structure & Mesh Frame

The best steel raw material,metallic luster,exquisite surface treatment，smooth and shiny
Main load-bearing beams: 100 x 150 x 3.0mm high-quality special-shaped steel pipe; Main load-bearing columns: 50 x 100 x 3.0mm high-quality steel pipe; Mesh frame beams: 100 x 150 x 3.0mm high-quality special-shaped steel pipe;
30 x 50 x 2.0mm high-quality steel pipe, welded mesh wire diameter 4mm, hole spacing 50mm x 50mm

QF-BQ014 板式网球场地渲染图4

QF-BQ014 板式网球场地渲染图8

Artificial Turf

Type: Textured filament artificial turf, the fiber completely encapsulate the sand; minimumrisk of abrasion;
Adhesive: double PP+PU;
Height: 12mm; dtex: 13600;Density: 46200; Gauge: 3/16;
Standard: UNE: 41958 IN, GB/T20394-2013 5. Sand filling: 60-100 mesh silica sand

Tempered Glass

Thickness:12mm
Size:2995mmX1995mm(18 pcs)
High strength, The strength is several times higher than that of ordinary glass,Transparent
Laminated glass optional

Safe to use, its load-bearing capacity is increased and its fragile nature is improved. Even if the tempered glass is broken, it will be small fragments without sharp angles, which greatly reduces the harm to the human body.

glass3-1

Tempered glass

Flood LED Light

Lighting: 400W LED lights, input voltage 220V.

Small size, no preheating required, fast start-up, safe and environmentally friendly Whether it is day or night, you can have a better experience

Customized service

With years of process technology, we can make the best configuration according to your actual needs to achieve the best sports experience for you.

Turf color customization:pink,green,blue,red,black ect.
Steel structure color customization:blue,green,gray ect.
Logo customization:color,logo can be customized
Glass option:tempered glass,laminated glass
